EUCHNER ESM-2H201 SAFETY RELAYS

Mekanik Değerler ve Çevre

Housing material
Housing Polyamide PA6.6
Weight
Net 0,23 kg
Ambient temperature
At UB = 24V AC -15 … 40 °C
At UB = 24V DC -15 … 60 °C
Degree of protection IP20
Mechanical life
operating cycles 10 x 106
Contact material AgSnO2
Mounting method Mounting rail 35mm according to DIN EN 60715 TH35
Connection Connection terminals
Length of control cable
With conductor cross-section 0.75mm2 1000 m
Safety contacts 13/14, 23/24
Number of safety contacts 2

Elektriksel Bağlantı Değerleri

Operating voltage
AC/DC 24 V -10% … +10%
Rated insulation voltage Ui 250 V
Rated impulse withstand voltage Uimp
Leakage path/air gaps 4 kV
Overvoltage category according to IEC EN 60664-1 3
Reverse polarity protection
On version UB =24V DC
Connection rating
at 24V DC 1,5 W
Degree of contamination (external, according to EN 60947-1) 2
Connection cross-section 0,14 … 2,5 mm²
Test voltage
Control system/contacts 2,5 kV
Control voltage
On S12-S13 and on S22 and S23 24 V
Control current
Both push buttons 40 mA 2x
LED indicator 2 status displays (green) for relays K1 and K2
Safety contacts 13/14, 23/24
Type of output
NO Relay contacts, floating and positively driven (redundant)
Switching voltage
AC max.250 V
DC max.24 V
Switching current min.20 mA at 24V
Fusing
External contact fuses (safety circuit) according to IEC 60269-1 10A gG
Utilization category acc. to EN 60947-5-1
AC-15 3A, 250V
DC-13 3A, 24V
AC-12 6A ohmic load, 250V
DC-12 6A ohmic load, 24V
Breaking capacity according to UL 6A 250V AC / 2A 24V DC
Delay time
After operation of the push buttons max.0,02 s Response delay time
Release time max.0,02 s
Synchronization time max.0,5 s

Çeşitli

In compliance with EN 60947-5-1: 2004+A1: 2009; EN ISO 13849-1: 2015; EN 62061: 2005 + AC: 2010 + A1: 2013 + A2: 2015; EN 50581: 2012 (RoHS)

EN ISO 13849-1 uyarınca güvenilirlik değerleri

Performance Level PL e
Category 4
PFHD 1.2 x 10-8
Number of switching cycles
≤ 3 A at 24 V DC max.22500 1/Jahr
≤ 1 A at 24 V DC max.100000 1/Jahr
≤ 0.1 A at 24 V DC max.400000 1/Jahr
Mission time 20 y
