Ex-Proof Bobinli Solenoid Valfler
Genel Maksat Direk Etkili Solenoid Valfler
Genel Maksat Pilot Kumandalı Solenoid Valfler
Kromschroder VAS240R/NW 88018371 Solenoid Valves
SMC AR25-F02-A Regulator
Cost effective and clean looking, series AR regulators offer various pressure range settings to accommodate most applications. The locking adjustment knob prevents accidental setting changes. The modular design of the AR series connects with other SMC air preparation equipment.
- Internal pilot relieving style (pilot air is always bleeding)
- Port sizes ranging from 1/4 to 2
- Optional bracket and pressure gauge
SMC AR30-F03E Regulator
Cost effective and clean looking, series AR regulators offer various pressure range settings to accommodate most applications. The locking adjustment knob prevents accidental setting changes. The modular design of the AR series connects with other SMC air preparation equipment.
- Modular type regulator
- Optional embedded pressure gauge
- Available with built-in backflow mechanism
- Knob is made of ozone resistant rubber material (HNBR)
- Improved relief sensitivity
- 6 Sizes
- Rc, NPT or G(PF) threads
SMC ARX20-F02B Regulator
Series ARX20, piston type regulator, is compatible with a primary supply pressure of 2.0MPa and is ideal for pressure adjustment of air blowing applications. The ARX has a compact design with a width of 35mm and an overall length of 80mm. The piston operated design ensures long operating life. The ARX has an easy-to-operate adjustment handle.
SMC AW20-F02 FILTER/REGULATOR- AW SERIES
FILTER/REGULATOR- AW SERIES
SMC AW Series Filter Regulators take up less space and require fewer piping, thereby reducing installation costs. AW filter regulators are made of rugged materials designed to withstand high pressures and allow the user to use a wide range of set pressure.
Filter size 5 μm
Output set pressure range: 0.5 → 8.5 bar ( 487-1070 0 → 7 bar)
Maximum operating pressure 10 bar
SMC C85N16-60 ROUND BODY CYLINDER
The C85 series conforms to ISO 6432 and CETOP RP52P. The C85 is available in bore sizes 8mm through 25mm with standard strokes ranging from 10mm through 300mm. A unique rod packing design prevents entry of dust and the effectiveness of the seal is such that the C85 is suitable for use in extremely dusty environments. With abrasion resistant packings and replaceable nose seals, the C85 offers exceptional service life.
SMC CD55B32-80M-X1439 COMPACT CYLINDER
C55 double acting, air operated cylinders were designed to meet a broad range of automation machine applications. The C55 series achieves outstanding load performance due to its unique rubber bumpers, piston wear ring, and rod bushing. Standardized mounting options conform to both ISO 21287 and 6431.
- Construction is similar to the current CQ2 lateral load resistant specification
- Snap ring construction allows easy and quicker maintenance
- Auto switches can be mounted on any of the four sides of the cylinder tube
SMC CDJ2D10-30Z-B ROUND BODY CYLINDER
Series CJ2 miniature cylinders available in spring return, spring extend, or double acting offer stainless steel tubing and stainless steel rods. The series is available in bore sizes 6, 10, 16mm and stroke lengths from 1/2in. to 8in.. Mounting options include basic, foot, front flange, and double rear clevis. Series CJ2 is auto switch capable
- Standard double acting single rod
- Bore sizes: 6, 10, 16 *
- Strokes from 15mm through 200mm depending upon bore size
- Mounts: basic, foot, front flange, double clevis
- Variety of switches and a variety of lead wire lengths
