SIMATIC S7-300, cam controller, FM 352, electronic incl.
configuration package on CD
Supply voltage
Rated value (DC) 24 V
Input current
from load voltage L+ (without load), max. 200 mA
from backplane bus 5 V DC, max. 100 mA
Encoder supply
5 V encoder supply
● 5 V Yes
● Output current, max. 300 mA
● Cable length, max. 32 m
24 V encoder supply
● 24 V Yes
● Output current, max. 300 mA
● Cable length, max. 100 m
Power loss
Power loss, typ. 8.1 W
