SIMATIC DP, Electronics module f. ET200S, 2AI Standard I-2DMU 15 mm width, 4.. 20mA; 13 bit for 2-wire transducer Cycle time 65 ms/channel with SF LED (group fault)| Supply voltage | | Load voltage L+ | | ● Rated value (DC) | 24 V; From power module | | ● Reverse polarity protection | Yes; Destruction limit 35 mA per channel | | Input current | | from load voltage L+ (without load), max. | 80 mA | | from backplane bus 3.3 V DC, max. | 10 mA | | Power loss | | Power loss, typ. | 0.6 W | | Address area | | Address space per module | | ● Address space per module, max. | 4 byte | | Analog inputs | | Number of analog inputs | 2 | | permissible input current for current input (destruction limit), max. | 40 mA | | Cycle time (all channels) max. | Number of active channels per module x basic conversion time |
|
