SPH1
- Measuring range 2 – 12 pH
- Process temperature 0 – 60 °C
- Pressure range (relative to ambient) 0 – 6 Bar
- Body material Plastic ; pH element Glass
- Ceramic diaphragm high accuracy
- Connection 6 or 1.5 meter cable with BNC and boot plastic cover
- Single and double junction with KCL Gel
SPH 2
- Measuring range 2 – 12 pH
- Process temperature 0 – 60 °C
- Pressure range (relative to ambient) 0 – 6 Bar
- Body material Plastic ; pH Glass ;
- Pellon PTFE diaphragm high accuracy
- S8 connector (PG13,5 mm mechanical and S7 electrical)
- Single junction with KCL Gel
SPH3 WW
- Measuring range 2 – 12 pH
- Process temperature 0 – 80 °C
- Pressure range (relative to ambient) 0 – 6 Bar
- Body material Plastic ; pH element Glass
- Diaphragm open hole
- S8 connector (PG13,5 mm mechanical and S7 electrical)
- Double junction with KCL Gel
SPH4 HP
- Measuring range 0 -14 pH
- Process temperature 0 – 60 °C
- Pressure range (relative to ambient) 0 – 6 bar
- Body material glass for high temperature environmental
- pH element Glass; 2 single pore diaphragms
- S8 connector (PG13,5 mm mechanical and S7 electrical)
- Double junction with KCL Gel
SPH4 HT
- Measuring range 0 – 14 pH
- Process temperature 0 – 130 °C
- Pressure range (relative to ambient) 0 – 16 bar (25 °C) / 0 – 6 bar (130 °C)
- Body material Glass ; pH element Glass ;
- 3 ceramic diaphragms high performance
- S8 connector (PG13,5 mm mechanical and S7 electrical)
- Double junction with KCL Gel
SPH4 LC
- Measuring range 0 -14 pH
- Process temperature -10 – 40 °C
- Pressure range (relative to ambient) 0 – 0.5 bar or higher if pressurization by side-arm
- Body material glass for low pressure environmental
- pH element Glass ; One sleeve diaphragm
- S8 connector (PG13,5 mm mechanical and S7 electrical)
- Double junction with KCL Gel
