CTK100
- Measuring range 0.04 – 20 μS
- Process temperature 0 – 130 °C
- Pressure range (relative to ambient) 0 – 16Bar
- Cell constant 0,01 cm¯¹ or K = 100
- Body material SS316; Electrodes material SS316
- Cable 5 meter ; Mechanical connection ½”Gas M
CTK10 PT
- Measuring range 0.01 – 500 μS
- Process temperature 0 – 70 °C
- Pressure range (relative to ambient) 0 – 7.5 Bar
- Cell constant 0,1 cm¯¹ or K = 10
- Body material Epoxy ; Electrodes material Platinum
- Cable 6 meter ; Mechanical connection 12 mm
CTK1 GR
- Measuring range 1 – 20000 μS
- Process temperature 0 – 100 °C
- Pressure range (relative to ambient) 0 – 6 Bar
- Cell constant 1 cm-1 or K = 1
- Body material PP glass reinforced ; Electrodes material Graphite
- Cable 5 meter ; Mechanical connection ½ Gas M
