PTC Resistor Relay Type MS220C

PTC-resistor relay, single PTC-circuit, Supply Voltage AC/DC 24-240 V

This compact device is the smallest version of all our PTCresistor relays.

• terminals outside
• protection terminals IP 20
• Relays 1 change-over-contact (co)

• Technical data

  Rated supply voltage Us

  ^…….
  AC/DC 24 – 240 V, AC 20 – 264 V, DC 20 – 297 V, < 1 W , < 4 VA

  Connectable PTC resistors

  ^…….

  1…6 PTC according DIN VDE V 0898-1-401 (formerly DIN 44081/82)

  Switching point

  ^…….

  < 4000 Ω

  Output relay

  ^…….

  1 change-over-contact (co)

  Type of contact

  ^…….

  Type 2 (see general technical information)

  Test conditions

  ^…….

  see general technical information

  Rated ambient temperature

  ^…….

  -20…+70 °C

  Dimensions h x w x d

  ^…….

  Design C: 72 x 33 x 60 [mm]

  Attachment

  ^…….

  on 35 mm DIN rail according to EN 60 715 or screws M4

  Protection Housing/Terminals

  ^…….

  IP30/IP20
