PILZ PNOZ po3.2p 4n/o 773631

Electrical data
Supply voltage (V) 24  V
Type of supply voltage U1 DC
Relay outputs
Utilisation cat. AC/DC1 stand. EN 60947-4-1
Voltage AC1 safety cont. 240  V
Max. current AC1 safety cont. 16  A
Voltage DC1 safety cont. 24  V
Max. current DC1 safety cont. 16  A
Utilisation cat. AC15/DC13sta. EN 60947-5-1
Voltage AC15 safety cont. 230  V
Max. current AC15 safety cont. 6  A
Voltage DC13 safety cont. 24  V
Safety contacts: AC at UL 240 VAC G. P.
Relay contact material AgSnO2
Addit. contact details relay + 0.2 µm Au
Environmental data
Climatic suitability to … EN 60068-2-78
Ambient temperature -10 – 55  °C
Condensation permitted? Not permitted
Vibration to standard … EN 60068-2-6
Overvoltage category III
Protection type, mounting
Protection type, housing
Terminal protection type
Mechanical data
Mounting position horizontal on top hat rail
Housing material upper part ABS UL 94 V0
Connection terminal Screw terminal
Terminal style plug-in
Flex. cond. c/s AWG info 20 – 10 AWG
Height dimension 94  mm
Width dimension 90  mm
Depth dimension 135  mm
Net weight 490  g
Gross weight
  • Açıklama
  • İnceleme (0)
  • Genel Bilgi

Açıklama

Electrical data
Supply voltage (V) 24  V
Type of supply voltage U1 DC
Relay outputs
Utilisation cat. AC/DC1 stand. EN 60947-4-1
Voltage AC1 safety cont. 240  V
Max. current AC1 safety cont. 16  A
Voltage DC1 safety cont. 24  V
Max. current DC1 safety cont. 16  A
Utilisation cat. AC15/DC13sta. EN 60947-5-1
Voltage AC15 safety cont. 230  V
Max. current AC15 safety cont. 6  A
Voltage DC13 safety cont. 24  V
Safety contacts: AC at UL 240 VAC G. P.
Relay contact material AgSnO2
Addit. contact details relay + 0.2 µm Au
Environmental data
Climatic suitability to … EN 60068-2-78
Ambient temperature -10 – 55  °C
Condensation permitted? Not permitted
Vibration to standard … EN 60068-2-6
Overvoltage category III
Protection type, mounting
Protection type, housing
Terminal protection type
Mechanical data
Mounting position horizontal on top hat rail
Housing material upper part ABS UL 94 V0
Connection terminal Screw terminal
Terminal style plug-in
Flex. cond. c/s AWG info 20 – 10 AWG
Height dimension 94  mm
Width dimension 90  mm
Depth dimension 135  mm
Net weight 490  g
Gross weight
