Overview
Technical Features
Detection properties
| Nominal sensing distance | 0,8mm |
| Operanting distance | 0…0,65mm |
| Standard target | 4x4mm FE360 |
| Correction Factor | copper: 0,2…0,5 / aluminium: 0,3…0,5 / brass: 0,4…0,6 / stainelss steel: 0,7…0,9 |
| Repeat Accuracy | < 3% (UB 24V Ta=23°C ±5°C) |
| Hysteresis | < 10% |
Application
| Description | M4 standard flush mount |
| Functions | Proximity |
Outputs
| Output type | NPN |
| Output Function | NO |
| Switching frequency | 2kHz |
| Response time | 0,25 |
Electrical data
| Operating Voltage | 10…30Vdc |
| No-Load supply current | ≤ 10mA |
| Load current | 100mA |
| Output voltage drop | < 1,5V |
| Max ripple content | ≤ 10% |
| LED indicators | Yellow LED output state |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Emission | ≥100kHz |
| Protection against inductive loads | Yes |
Mechanical data
| Dimensions | Ø4×25 |
| Mounting | Shielded |
| Material | Stainless steel |
| Housing material | Stainless steel |
| Connections | 2m PVC Cable |
| Active Head Material | POM |
| Diameter/Dimension | M4 |
Test/Approvals
| Approvals | CE |
Generical Data
| Dimensions | Ø4 / L = 25mm |
| Operating Temperature | -25°C…+70°C |
| Mechanical Protection | IP69K |
