G9SX

Esnek emniyet ünitesi

G9SX ailesi modülleri makinenin kısmi/tam kapanması için mantıksal “AND” (VE) fonksiyonu ile bağlanabilir. Solid state çıkışları, ayrıntılı LED teşhisleri ve akıllı geri besleme çıkışları bakımın kolay yapılmasını sağlar. Seri, güvenli zamanlama fonksiyonları olan genişletme üniteleri ile tamamlanır

Emniyet fonksiyonlarının eşsiz “AND” (VE) bağlantısı kullanılarak açık ve şeffaf segmentasyon
Uzun ömür için solid state çıkışları ve genişletilebilir röle çıkışları mevcuttur
Ayrıntılı LED göstergeleri kolay sistem kontrolünü sağlar
Kolay bakım için akıllı geri besleme çıkışları
Kategori 4 EN954-1 ve SIL 3 EN 61508;

Ordering information

Advanced unit

Safety outputs		Auxiliary outputs	No. of input channels	Max. OFF-delay time 1	Rated voltage	Terminal block type	Order code
Instantaneous	OFF-delayed	Auxiliary outputs	No. of input channels	Max. OFF-delay time 1	Rated voltage	Terminal block type	Order code
3 P channel MOS-FET transistor output	2 P channel MOS-FET transistor output	2 PNP transistor outputs	1 or 2 channels	0 to 15 sec in 16 steps	24 VDC	Screw terminals	G9SX-AD322-T15-RT
3 P channel MOS-FET transistor output	2 P channel MOS-FET transistor output	2 PNP transistor outputs	1 or 2 channels	0 to 15 sec in 16 steps	24 VDC	Cage clamp terminals	G9SX-AD322-T15-RC
2 P channel MOS-FET transistor output	2 P channel MOS-FET transistor output	2 PNP transistor outputs	1 or 2 channels	0 to 150 sec in 16 steps	24 VDC	Screw terminals	G9SX-AD-322-T150-RT
				0 to 150 sec in 16 steps	24 VDC	Cage clamp terminals	G9SX-AD-322-T150-RC
				0 to 15 sec in 16 steps	24 VDC	Screw terminals	G9SX-ADA-222-T15-RT
				0 to 15 sec in 16 steps	24 VDC	Cage clamp terminals	G9SX-ADA-222-T15-RC
				0 to 150 sec in 16 steps	24 VDC	Screw terminals	G9SX-ADA-222-T150-RT
				0 to 150 sec in 16 steps	24 VDC	Cage clamp terminals	G9SX-ADA-222-T150-RC

Basic unit

Safety outputs		Auxiliary outputs	No. of input channels	Rated voltage	Terminal block type	Order code
Instantaneous	OFF-delayed	Auxiliary outputs	No. of input channels	Rated voltage	Terminal block type	Order code
2 P channel MOS FET transistor output	–	2 PNP transistor output	1 or 2 channels	24 VDC	Screw terminals	G9SX-BC202-RT
2 P channel MOS FET transistor output	–	2 PNP transistor output	1 or 2 channels	24 VDC	Cage clamp terminals	G9SX-BC202-RC

Expansion unit

Safety outputs		Auxiliary outputs	OFF-delay time	Rated voltage	Terminal block type	Order code
Instantaneous	OFF-delayed	Auxiliary outputs	OFF-delay time	Rated voltage	Terminal block type	Order code
4 PST-NO (contact)	–	2 (solid state) PNP transistor outputs	–	24 VDC	Screw terminals	G9SX-EX401-RT
4 PST-NO (contact)	–		–		Cage clamp terminals	G9SX-EX401-RC
–	4 PST-NO (contact)		Synchronized with G9S-X-AD – unit		Screw terminals	G9SX-EX041-T-RT
–	4 PST-NO (contact)		Synchronized with G9S-X-AD – unit		Cage clamp terminals	G9SX-EX041-T-RC

Specifications

Power input

Item	G9SX-AD_	G9SX-BC202-_	G9SX-EX-_
Rated supply voltage	20.4 to 26.4 VDC (24 VDC -15% +10%)

Inputs

Item	G9SX-AD_	G9SX-BC202-_
Safety input	Operating voltage: 20.4 VDC to 26.4 VDC, internal impedance: Approx. 2.8 kΩ
Feedback/reset input

Outputs

Item

G9SX-AD_

G9SX-BC202-_

Instantaneous safety output
OFF-delayed safety output

P channel MOS FET transistor output

Load current: Using 2 outputs or less: 1 A DC max.

Using 3 outputs or more: 0.8 A DC max.

P channel MOS FET transistor output

Load current: Using 1 output: 1 A DC max.

Using 2 outputs: 0.8 A DC max.

Auxiliary output

PNP transistor output
Load current: 100 mA max.

Expansion unit

Item	G9SX-EX-_
Rated load	250 VAC, 3A/30 VDC, 3A (resistive load)
Rated carry current	3 A
Maximum switching voltage	250 VAC, 125 VDC

Characteristics

Item		G9SX-AD_	G9SX-BC202-_	G9SX-EX-_
Operating time (OFF to ON state)		50 ms max. (Safety input: ON) 100 ms max. (Logical AND connection input: ON)	50 ms max. (Safety input: ON)	30 ms max.
Response time (ON to OFF state)		15 ms max.		10 ms max.
Durability	Electrical	–		100,000 cycles min.
Durability	Mechanical	–		5,000,000 cycles min.
Ambient temperature		-10°C +55°C (with no icing or condensation)
