ECKERLE EIPS1-016RD01-10 – EIPS segment pump – mobile hydraulic

ECKERLE EIPS1-016RD01-10 – EIPS segment pump – mobile hydraulic

Teknik veri
1.500 dev / dak’da pompa hacmi (l / dak) 2.4
Nominal ölçü 16
Vth – özgül hacim (cm³ / dev) 1.6
Maks. Alan sayısı hız (rpm) 4000
Kalıcı çalışma basıncı (bar) 300
Tepe çalışma basıncı (bar) (aralık) 320
Dalga ucu tang mili

Kategoriler: Etiketler: , , , ,
  • Açıklama
  • İnceleme (0)
  • Genel Bilgi

Açıklama

IPS – the logical development of an innovation

The EIPS series was developed specially for the rigorous demands of mobile hydraulics. The pumps in this series are the result of our decades of experience in the development of internal gear systems.

Now, the new EIPS1 is available who is ideally suited for small flow rates for variable speed applications with very high efficiency. They feature especially low-noise operation, excellent levels of efficiency, compact design, continious operating pressure up to 320 bar and long service lives.





NEW DEVElOPMENT

Pumps for mobile applications

  • Electric-powered forklifts
  • Diesel-powered forklifts
  • Gas-powered forklifts
  • 2Q-operation pump/hydro motor
  • Decentralized high-efficiency low-voltage-hydraulic units
