Overview
- Flexible and intuitive setup via PC through Ethernet
- Memorisation of 20 inspections
- 14 different controls
- 360° Contour Match for Professional models
- Logical operators: AND, OR, NOT,NAND, NOR, ecc.
- TURBO mode to double elaboration speed
- VSM compatibility
- Inspection & Identification functionalities together
available on Professional models
Technical Features
Detection properties
| Nominal sensing distance | 500mm |
| Sensitivity adjustment | Teach-in/GUI |
Application
| Function Principle | ID Barcode/Datamatrix/QR/OCV |
| Description | Block style case – Lens 16 mm |
| Optic position | Radial 90° |
| Functions | ID Barcode/Datamatrix/QR/OCV |
Outputs
| Output type | 3xPNP, RS232, Ethernet |
| Response time | 50 |
Electrical data
| Operating Voltage | 24VDC |
| Short-circuit protection | YES |
| Reverse Polarity Protection | Yes |
| Emission | LED Red |
| Impulsive Overvoltage Protection | Yes |
| Insulation resistance | >20 MΩ 500 Vdc, between electronics and housing |
| Contact resistance | 500 Vac 1 min., between electronics and housing |
Mechanical data
| Dimensions | 52x60x40 |
| Material | |
| Housing material | Metal – Aluminium / ABS |
| Connections | M12 plug |
| Active Head Material | PMMA |
| Storage temperature | – 25°C…+70°C |
Test/Approvals
| Approvals | CE cULus |
| Shocks and vibrations | 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6) |
Generical Data
| Dimensions | 52x60x40 |
