CombiLyz AFI4 Serisi İletkenlik Transmitteri

Main features

„ Range from 500 µS/cm to 1 S/cm
„ All hygienic design
„ Built in graphical display
CombiView DFON
„ Very fast temperature compensation
„ Easy and full programmable
with FlexProgrammer 9701
„ Separate 4…20 mA output
for conductivity / concentration and 4…20 mA output for
temperature
„ FDT software
„ 3A approved
„ EHEDG
„ Touch screen

Applications
„ Controlling CIP procedure
„ Controlling filling machines
„ Detection of specific medias
„ Water systems with >50 µS/cm

  • Açıklama
  • Yorumlar (0)
  • Genel Bilgi

Açıklama

Technical specifications

Housing material FlexHousing, Ø80 mm
Stainless steel, AISI 304
Process connection G1A, rotating
(for other connections see adapters page 4)
Insertion length Standard
Long version
37 mm / 3A version 40.5 mm
83 mm / hygienic version 87 mm
Material Not wetted
Wetted parts
Stainless steel AISI 304
PEEK natura, unfilled
Surface Wetted parts Ra < 0.8 µm
Measuring range Conductivity
Concentration
Temperature
0 … 500 µS/cm … 0 … 1.0 S/cm
14 selectable ranges
4 factory set media/ranges
1 customer defined media/range
-30 … 150°C
Free programmable range
Accuracy
(sensor incl. transmitter
@ 25°C ambient)
Cond./conc.
Temperature
0 … 500 µS/cm ≤ 1.5 %
0 … 1 / 0 … 500 mS/cm ≤ 1.0 %
0 … 1 S/cm ≤ 1.5 %
≤ 0.4 % selected range
Temperature compensation 0.0 … 5.0% / °C, free adjustable
Compensation range -20 … 150°C
Reference temperature 25°C (adjustable)
Sampling time < 0.3 second
Response time Cond./conc.
Temperature
t
90 < 2.0 seconds
t
90 < 15 seconds
Start up time without display ≤ 10 seconds
Start up time with display ≤ 15 seconds
